New
Atlantic Cat5 SFTP 305M OUT Cable – Shielded, High-Speed, Flame-Retardant, 24AWG, LSZH Jacket, Tested to 100MHz
135,000 د.ع
الوصف
- 24 AWG copper wire insulated with Polyethylene
- Two insulated conductors twisted together to form a pair, four such pairs covered by Aluminum foil polyester tape
- Core unit overall braided with ATC, jacketed with flame retardant PVC/LSZH
- Enhanced performance cable enables delivering high speed network
- Flame Rating: PVC-CM, LSZH – IEC 60332-1, IEC 60754 1&2, IEC 61034-2
- Very good RFI/EMI interference attenuation for high electrical noise locations
- Specified and tested up to 100MHz
- Compliant to ANSI/TIA 568-C.2, ISO/IEC 11801 Class D
- 25 years system warranty available
- Product Application:
- 10 Base T (IEEE 802.3)
- 100 Base T (IEEE 802.3U)
- 1000 BASE-T (IEEE 802.3ab)
- TP-PMD (ANSI X3T9.5)
- 100 Mbps CDDI
- ATM 155
- 4/16 Mbps Token Ring (IEEE 802.5)
- Meets IEEE802.3af & 802.3at PoE
- Jacket Colours: Blue, Grey or Customer Specific Colours
- Colour Code:
- Pair 1: Blue – White Blue
- Pair 2: Orange – White Orange
- Pair 3: Green – White Green
- Pair 4: Brown – White Brown
- Product Specification (Mechanical & Environmental Characteristics):
- Maximum tensile load: 110 N (installation)
- Minimum bend radius: 8 × cable outer diameter
- Temperature: 0°C to +50°C (installation), -10°C to +60°C (operation)
