الوصف
  • Application : Client PCs, Game Consoles
  • Capacity : 4,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
  • Interface : PCIe Gen 4.0 x4, NVMe 2.0
  • Dimension (WxHxD) : 3.15 x 0.87 x 0.091 inches
  • Weight : Max 0.02 lbs
  • Form Factor : M.2 (2280)
  • Storage Memory : Samsung V-NAND TLC
  • Controller : Samsung in-house Controller
  • Cache Memory : Samsung 4GB Low Power DDR4 SDRAM
  • Sequential Read : Up to 7,450 MB/s * Performance may vary based on system hardware & configuration
  • Sequential write : Up to 6,900 MB/s * Performance may vary based on system hardware & configuration
  • Random Read (4KB ,QD32) : Up to 1,600,000 IOPS * Performance may vary based on system hardware & configuration
  • Random Write (4KB ,QD32) : Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration
  • Random Read (4KB ,QD1) : Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
  • Random Write (4KB ,QD1) : Up to 80,000 IOPS * Performance may vary based on system hardware & configuration
  • Temperature : 32°F – 158°F (0 – 70 ℃ Operating Temperature)
  • Shock : 1,500 G & 0.5 ms (Half sine)
    Management SW : Magician Software for SSD management
  • TRIM Support : Supported
  • S.M.A.R.T Support : Supported
  • GC (Garbage Collection) : Auto Garbage Collection Algorithm
  • Encryption Support : AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
  • WWN Support : Not supported
  • Device Sleep Mode Support : Yes
  • Average Power Consumption (system level) : *Average: 6.5 W*Maximum: 8.6 W (Burst mode)*  Actual power consumption may vary depending on system hardware & configuration
  • Power consumption (Idle) : Max. 55 mW * Actual power consumption may vary depending on system hardware & configuration
  • Allowable Voltage : 3.3 V ± 5 % Allowable voltage
  • Reliability (MTBF) : 1.5 Million Hours Reliability (MTBF)
